What do we know about volcanoes?

Volcanoes are commonly divided into three basic types, although not all fit neatly into one of these categories. These are shield volcanoes, composite cones, and calderas.

Shield volcanoes are low and rounded, shaped like a warrior’s shield. They get this shape because the lavas that form them are relatively hot and fluid compared to other lavas. Because the lavas flow easily, they do not pile up to form steep-sided cones, but instead may flow for miles or tens of miles before they cool. Although these volcanoes produce some ash and coarser materials, lavas usually dominate. Any volcano is dangerous, but shield volcanoes are generally the least dangerous.

Composite cones are some of the most spectacular and famous volcanoes, for example Mt. Vesuvius web cam link, Mt. Rainier, or Mt. St. Helens web cam link (which was our last big eruption in the United States). The lavas that form composite cones are not as hot or as fluid as the lavas that form shield volcanoes. Therefore, they tend to pile up and make the classic, and beautiful, volcanic cone with steep sides rather than spread out for many miles.

These volcanoes can be very explosive, and therefore dangerous. They are much less predictable than shield volcanoes. Even though Mt. St. Helens was being monitored very carefully prior to its eruption in 1980, the way it erupted was a surprise, and dozens of people were killed. Another hazard associated with composite cones is landslides (most commonly mudflows). The steep sides of the volcanic cone combined with lots of fairly loose volcanic ash and debris created by explosive eruptions can create massive mudflows when saturated with water. These mudflows may travel down canyons at tens of miles per hour, overwhelming everything in their path. Large mudflows sometimes kill thousands of people where towns have been built in their path.

Volcano Informaiton Sites



Volcano world from Oregon State
The Smithsonian Institution's Global Volcanism Program —MT Etna 2-9-2012


How to predict volcanoes

Calderas are the champions of volcanoes, and are generally the least-recognized. Yellowstone National Park owes its spectacular geysers, steaming fumaroles, and hot springs to a caldera-forming eruption that happened about 600,000 years ago. If you visit Yellowstone, it does not look like a volcano. That’s because it is so big (the caldera is about 25 miles by 45 miles across), and it did not form a big volcanic cone like Mt. Rainier.

In these highly explosive volcanoes the magma has a high resistance to flow, and also contains a large amount of gases (mostly steam). As the magma nears the earth’s surface, the pressure from the overlying rocks is no longer sufficient to hold the gases inside the magma. As a result, the gases literally blow the magma apart, creating great volumes of volcanic ash and coarser debris. This material forms very hot, dense clouds that move along the earth’s surface at speeds that may exceed 100 miles per hour. It was a cloud of this type that did much of the damage when St. Helens erupted in 1980.

Imagine taking a bottle of soda pop and shaking it up as you hold your thumb over the top of the bottle. When you remove your thumb, the insides of the bottle comes foaming out, spurting into the air and flowing down the side of the bottle. This is similar to what happens in an explosive volcanic eruption. In fact, so much magma is blown out as ash that the overlying crust collapses, leaving a hole at the surface that may be over 10 miles across and a mile or more deep. This hole is the caldera. In large calderas this hole commonly fills with the volcanic ash being erupted.

Many calderas have formed in the geologic past, but we have never witnessed a large caldera-forming eruption since man first began writing down history. We probably don’t want to! The large eruptions would be capable of altering the earth’s climate for several years, and the ash erupted could destroy human habitation over an area that could easily cover several states


Make a mock volcano that erupts when you mix baking soda and vinegar.

This is a very messy project—especially at the end when the volcano erupts. Wear old clothes and work on a pile of newspapers (or even better, outdoors).

In a real volcano, molten rock from deep within the Earth erupts through a volcano (the molten rock is called magma when it is within the Earth and is called lava when it comes volcano diagram (courtesy of USGS)out of a volcano). In this project, a mock volcano will erupt with a bubbly, fizzy liquid that is created by a simple chemical reaction.

This project shows what happens when an acid (vinegar) and a base (baking soda) interact. Chemically, the acid and base neutralize each other, producing carbon dioxide gas as a byproduct. The exact reaction is:

HC2H3O2 (vinegar = acetic acid) + NaHCO3 (baking soda = sodium bicarbonate) = CO2 (carbon dioxide gas) + NaC2H3O2(sodium acetate) + H2O (water)



Model Volcano
(parental supervision is advised)

Begin by gathering all your ingredients; you should have everything you need around the house.

What you'll need:

  • Aluminum cookie sheet
  • Cardboard box
  • Lots of old newspaper
  • Baking soda (about 3-4 tablespoons)
  • Vinegar (about 1/2 cup)
  • A few drops of liquid dishwashing detergent
  • Small plastic bottle (like a small pop bottle)

ingredients

Choose a spot to build your volcano that is okay to occupy for a couple of days because the volcano will need time to dry. You should also choose a spot that is easy to clean up—this project is messy! Your backyard would be an ideal location, if the weather is good.

Spread newspapers over your work area.

Use a large piece of cardboard as a platform for your volcano. A large tray or cookie sheet with sides all the way around will help contain your volcanic eruption. Cut the cardboard to fit inside the tray.

Try to find a small beverage bottle, so that you can use less clay to model your volcano. A 16-oz soda bottle will require about three batches of clay. This can get quite heavy if you want to move the volcano. Some people use papier mache' for part of the volcano to make it lighter. However, if you want to keep the volcano and use it again, modeling clay is best.

Cut the neck off the bottle at a slight angle. This creates a wider opening for the lava flow, and the angle makes the volcano opening look more realistic. Glue the bottle to the center of the cardboard base. Let it dry for about an hour.

You may then add all of the ingredients for the first eruption except the baking soda to the bottle (vinegar, dish soap, and red dye).

mix up the mountain




While you wait, mix your clay. Begin by mixing the flour and salt. Then add the water and mix with your hands until you have a clay-like consistency. It must be moist enough to hold together, but as dry as possible, so it doesn’t take too long to cure.

Start building your volcano from the bottom, molding the clay around the base and working toward the top. Remember, you need a wide bottom and a narrow top. When you run out of clay, let the volcano dry for awhile before mixing another batch. Sometimes if the volcano dries on the outside and the inside is still moist, the inside will expand, creating surface cracks and fissures. This is okay because that is what happens in real volcanoes. But if the interior is too moist, the weight will cause the whole thing to break away from the bottle. Volcanoes look like mountains, so lumps and bumps are good. You can also sculpt erosion gullies and lava channels after the volcano has dried for awhile.

Let the volcano completely dry before you paint it. Use a base color like brown to paint the entire volcano and the base. Then paint green for trees, white for snow at the top, etc. Or you can use entirely different colors–whatever your imagination dictates. If you want texture, you can sprinkle fine sand on the wet paint. You can use small twigs and grass for trees, but remember, you are building a mountain, so individual trees would be difficult to see from your perspective.

When the paint dries, you will be ready for the eruption. Place your baking soda in a small square of tissue. Gather the edges and twist them together. Drop the baking soda into the volcano, wait several seconds, and you will begin to see your eruption.

Your volcano should be very durable, so you can keep it and erupt it many times if you like. Just remember that the eruption is messy and plan accordingly.
